Product Details:
|
| After-sales Service Provided: | Free Spare Parts | Warranty: | None |
|---|---|---|---|
| Type: | Other Home Appliance Parts | Application: | Household |
| Power Source: | Electric | Voltage Current: | CUL :125V/16A ;VDE : 250V / 12A |
| Endurance Test Cycle: | 100,000 Times | Operating Temperature: | 50-250 ℃ |
| Tolerance: | 5℃% | Port: | Guangzhou |
Electrical Performance | 10A/AC250V16A/AC 250V | ||||||
Temperature Range | 0 ºC-250°C | ||||||
Ambient Temperature | T250°C | ||||||
Wiring | A. Terminal Blocks :M4,M3 B.Plug terminal : 250#187#(0.8mm thick and bending: 30°,45°,90°,180°is available) | ||||||
Product Cycles | 100,000cycles | ||||||
Thermostat Shaft Rotation Angle | 150°,180°,210°,250°,270°,300°,310° | ||||||
Electrical Strength | AC2000V/0.5mA/min | ||||||
Insulation Resistance | >100MΩ | ||||||
Contact Resistance | ≤50MΩ | ||||||
Grounding Method | Mounting plate or install oranges electrical enclosure parts connected by thermostat | ||||||
